*Major order intake news is basically and collectively updated every three month.
News 2015
-
[ 10 December 2015 ]
Torishima receives order for a package of pumps for seawater desalination plant and gas-fired power plant in Qatar from Samsung C&T.
Qatar is located along the Persian Gulf on the Arabian Peninsula and has an area of 11,427 square kilometers, a population of approximately 22.6 million, and the 3rd largest natural gas reserve in the world following Iran and Russia. With a rapidly growing population and increasing development, a number of infrastructure initiatives such as the construction of new roads, transport and hotels have also been launched in Qatar, in preparation for the FIFA World Cup in 2022.
As a part of the initiatives, a big project constructing a seawater desalination plant and a gas-fired power plant has been launched in the suburbs of the capital city, Doha. Samsung C&T Corporation, the largest general trading company and constructor in South Korea, will undertake the construction of both plants.
Torishima has received orders for seawater intake pumps for the seawater desalination plant and boiler feed pumps for the power plant. Both types of pumps play a vital role in the seawater desalination plant and power plant respectively and consequently must have high reliability and high efficiency. Torishima has a proven track record and a high reputation in supplying these pumps, which was decisive in winning the order.
This project is expected to ensure the stable supply of water and electricity in Qatar, and is scheduled to be completed in June 2018. Torishima will be committed to the development and prosperity of the country with its pumping technology.Pumps Main seawater pumps for
CondenserMain seawater pumps for Early power Main seawater pumps for
MSFMain seawater pumps for
ROMain seawater pumps for
RedundencyBoiler feed
pumpsSize/Type SPV1350 SPV600 SPV1350 SPV1200 SPV1350 MHG6/6 Quantity 8 units 4 units 5 units 4 units 2 units 12 units Capacity 19,900m³/hr 3,100m³/hr 19,200m³/hr 14,300m³/hr 19,200m³/hr HP:690m³/hr
IP:86m³/hrTotal Head 21.4m 33.4m 32.1m 20.7m 32.1m HP:1,132m
IP:390mMotor Rating 1,640kW 400kW 2,210kW 1,100kW 2,210kW 3,000kW - [ 10 December 2015 ]
Torishima receives order for brine recirculation pumps for seawater desalination plant in Qatar from Hitachi Zosen Corporation
Name of Pump Boiler recirculation pump Size / Type CDKTV1200 Quantity 10 units Torishima has received an order for brine recirculation pumps for a large scale seawater desalination plant in Qatar from the Hitachi Zosen Corporation, who will be undertaking the construction of the plant.
This plant will use a hybrid desalination system composed of two different desalination processes: MSF (Multi-Stage Flash), an evaporation process and RO (Reverse Osmosis), a membrane process. The capacity is expected to amount to approximately 590,000 cubic meters per day.
Being the heart of the MSF method, Brine recirculation pumps are required to have high suction performance and high efficiency. Torishima’s double-suction vertical type brine recirculation pumps won the approval in these areas, resulting in the order.
With growing population and industrialization in emerging countries, the demand for pure water is inevitably increasing. Toshima plays a significant role in solving the water shortage as a leading pump manufacturer, and is committed to this project, drawing on its long experience and expertise in pumping technology.
- [ 11 November 2015 ] Presentation Material of Consolidated Financial Results for the 2Q FY2015
- [ 11 November 2015 ] Consolidated Financial Results for the 2Q FY 2015
- [ 04 November 2015 ]
Torishima to exhibit at "POWER-GEN International" in the USA
Torishima will exhibit at“POWER-GEN International", which is one of the largest international shows in the power industry.
More than 1,400 exhibitors from all sectors of the industry and over 22,000 attendees from 90 countries are expected to join this year.
Torishima will display mechanical seals and cut models of boiler feed pumps.
Please visit Torishima booth and find out more about our advanced products for power industry.
We look forward to seeing you.-
- Date : December 8 (Tue.) - 10 (Ths.)
- Venue: Las Vegas Convention Center, NV, USA
- Torishima Booth: 8141
Official website: www.power-gen.com
-->
-
-
[ 10 September 2015 ]
Torishima receives an order for construction of the "Project for Upgrading of Mechanical System for Sewerage and Drainage Service" in Gujranwala
Torishima has received an order for construction of the Project for Upgrading of Mechanical System for Sewerage and Drainage Service in Gujranwala from Water and Sanitation Agency (WASA), Gujranwala.
Gujranwala is the 7th biggest city in Pakistan and located in Panjab, 250km northeast of Harrapa which is a well-known archaeological site of the Indus Civilization. Besides the ancient civilization, this area is profoundly influenced by different cultures and history such as the eastern expedition by Alexander and Buddhist art which flourished during the era of Gandhara. Actually, despite the fact that Muslims account for 97% of the total population in Pakistan, you can find a variety of important cultural properties in the museum such as Buddha statues and relics of the British colonial period as well as Islamic collections.
The downtown area of Gujranwala is situated at a strategic point along with the major Grand Trunk Road highway, commonly called G.T. road, stretching from east India to west Afghanistan. The road however, has been experiencing flood damage in recent years due to the worsening performance of aging drainage pumps, especially from July to September with the high frequency of monsoonal downpour. This obstructs the flow of goods, services and people.
In order to solve this problem, Japan International Cooperation Agency (JICA) and the Pakistani government came to an agreement that 9 pumping stations within the area would be updated under the initiative of Japan’s Official Development Assistance (ODA). Torishima won a bid and received the order for supply and installation of pumps, motors, intermediate shafts, piping equipment, electric switchboards and in-house generation systems. We have launched a special team for this project, and have proceeded with the design and production work. The project is expected to be completed in December 2016.Pumps Disposal pump Disposal pump Disposal pumps Disposal pump Size/Type CFV450 CFV400 CFV300 CFV200 Quantity 1 units 1 units 11 units 1 units Capacity 34m³/min 25.5m³/min 17m³/min 6.8m³/min Total Head 15m 15m 15m 15m Motor Rating 132kW 100kW 65kW 37kW -
[ 10 September 2015 ]
Torishima receives an order
for a total of 23 pumps for a water treatment plant
Torishima has received an order for a total of 23 pumps for a water treatment plant capable of producing 360,000 m³/min water a day as pre-treated water for a desalination plant in Basrah, Iraq from OTV France.
OTV is an EPC contractor of water treatment facilities, and a subsidiary of VEOLIA, who is one of the “Water Barons” and dominates 80% of privatized water and wastewater utilities in the world.
This desalination plant is to take the water from a river, and Torishima pumps will be used for water intake, transmission and distribution applications.
Having constantly been devastated by conflicts, water facilities in Iraq are urgently in need of being repaired and developed. Especially in the southern part of the country, with low rainfall compared to the northern part, water shortage has been a serious concern.
We will continuously contribute to reconstruction and providing solutions for water shortage with pumps in Iraq, where new development schemes for water infrastructure are expected in the years to come.Pumps Intake pumps Clear water transmission pumps Clear water distribution pumps Clear water
traasfer pumps
to Basrah unifiedSize/Type CDM700×600KBA CDM700×600 CDM400×300GN CDM400×350KN Quantity 10 units 4 units 3 units 6 units Capacity 3,750m³/h 5,400m³/h 1,520m³/h 1,170m³/h Total Head 19.5m 32m 80m 15m Motor Rating 270kW 700kW 500kW 75kW - [ 31 August 2015 ] Annual Report 2015
- [ 05 August 2015 ] Consolidated Financial Results for the 1st quater FY2015
- [ 10 June 2015 ]
Torishima Europe Limited receives an order for Boiler Feed Pumps
for Los Mina Combined Cycle Conversion Project from TECNICAS REUNIDASName of Pump Boiler feed pump Size / Type MHG4/7 Quantity 4 units Capacity 212.9m³/h Total Head 1.253m Motor Rating 1,040kW Torishima Europe Limited has received an order for Boiler Feed Pumps for Los Mina Combined Cycle Conversion Project.
TECNICAS REUNIDAS S.A (TR) is one of the most influential general contractors engaging in the engineering, design and construction of industrial facilities, especially in Oil & Gas, in the world.
They have many experiences in various fields all over the world, for example Saudi Arabia, South America and Europe. Torishima is pleased to work with TR for the first time.
Another special note is that this is the first time to export Torishima’s pump to Dominican Republic, which is located in the Hispaniola islands in the Caribbean Sea. Columbus took possession of this island in 1492 and later Spain constructed the first colonial city in New World. Los Mina Power Plant is near the capital city, Santo Domingo. The city is located in the south of the country and we still can see some buildings which is reminiscent of the Spain at that time.
The plant is a Simple Cycle Power Plant and two 105MW simple-cycle natural gas-fired turbines are in operation there. And it is operated by Dominican Power Partner which is subsidiary of AES Dominicana. The company and another subsidiary, AES Andress B.V. own and operate power generation units that have 555 MW of installed capacity. The number represents approximately 17% of the current total installed capacity in the country. Los Mina Power Plant plays an important role and sustains the people’s life.
The conversion enables the plant to increase its capacity from 210 MW to 324 MW without using additional gas. With regard to environment impact, it will reduce 330,000 tons of CO2 per year.
We hope to maintain a good relationship with TR to encourage good future business opportunities. - [ 10 June 2015 ]
Torishima receives an order for 8 Boiler Recirculation Pumps (CPW)
for a combined cycle power plant in Djelfa, Algeria, from Nooter/Eriksen (N/E).Name of Pump Boiler recirculation pump Size / Type CPW150-315 Quantity 8 units Capacity 402m³/h Total Head 113m Motor Rating 160kW Torishima received an order for quantity 8 Boiler Recirculation Pumps (CPW) for a combined cycle power plant in Djelfa, Algeria, from Nooter/Eriksen (N/E).
Torishima’s experience with our CPW in these particular services and commercial competitive edge led to the successful partnership with N/E for this project.
N/E is a single source supplier of custom designed heat recovery systems. They are headquartered in St. Louis, Missouri, USA and are known as one of the world's leading independent suppliers of Natural Circulation Heat Recovery Steam Generators (HRSGs) combined with gas turbines.
HRSGs are used to capture exhaust heat from the gas turbine that would otherwise escape through the exhaust stack of combustion gas turbines.
The HRSG creates steam from the gas turbine exhaust heat, delivering it to the steam turbine adding the additional energy to the generator shaft.
N/E has sold more than 800 HRSG units and their vast experience list consists of units across the globe, including installations in the USA, Canada, Central America, South America, Europe, Africa, the Middle East, and Asia.
As Algeria’s economy continues to grow, so does the country’s energy demands. N/E’s HRSG and Torishima’s CPW pumps will contribute to satisfying those growing energy demands, thus supporting future economic growth. - [ 13 May 2015 ] Presentation Material of Consolidated Financial Results for FY2014
- [ 12 May 2015 ] Consolidated Financial Results for FY 2014
- [ March 2015 ]
Torishima Service Solutions receives an order for the EPC project with MARAFIQ,
the power and water utility company for Jubail and Yanbu.
Name of Pump Seawater pump Size / Type SPV1800 Quantity 2 units Capacity 34,500m³/h Total Head 23m Motor Rating 3,100kW Torishima Service Solutions FZCO has received the EPC project with MARAFIQ, the power and water utility company for Jubail and Yanbu.
The project is to design, manufacture, install, test and commission 2 seawater cooling pumps and all related mechanical, electrical, instrument and civil works for Jubail-2 main seawater cooling pumping station in the Kingdom of Saudi Arabia.The end user, MARAFIQ’s foundations were laid in the 1970s when the government established the Royal Commission to develop the two industrial cities of Jubail and Yanbu.
MARAFIQ is responsible for the operation, maintenance, management, construction, development, and expansion of the utility systems such as seawater cooling, seawater desalination, electric power generation, water transmission, and water distribution.Jubail city on the Arabian Gulf coast is located about 500 km to the east of the capital city Riyad. Jubail has a double pipeline for transporting oil and gas, running almost 1200 kilometers across the Arabian Peninsula to Yanbu on the west Red Sea coast of the Kingdom.
The pumping station currently comprises of 3 existing pumps and the 2 new pumps, which are to operate in parallel with the 3 existing pumps to pressurize seawater for industries in Jubail, and will be provided with Variable Frequency Drives (VFD) to enable the systems efficient operation at various flow-rates according to the seawater cooling demand.
In addition, the major wetted parts are designed by using Super Duplex Stainless Steel to protect against the highly corrosive seawater in the Middle East.The whole project is expected to be completed by June of 2016. We will satisfy MARAFIQ, maintaining a good relationship to encourage more future business opportunities.
- [ March 2015 ]
Torishima Hong Kong receives an order for a reverse pump axial turbine for
the Stonecutters Island Sewage Treatment Works in Hong Kong.
Name of Pump Reserve pump axial turbine Size / Type IST-PGV900×800 Quantity 1 unit Capacity 1.15m³/s Total Head 3m Motor Rating 21kW Torishima Hong Kong Ltd. (THK) has received an order for a reverse pump axial turbine (IST-PGV900×800, vertical axial-flow) for the Stonecutters Island Sewage Treatment Works managed by the Government of Hong Kong Special Administrative Region, Drainage Services Department (DSD).
Torishima delivered a number of engineered pumps to the Stonecutters Islands Sewage Treatment Works where two pumping stations were constructed under the government leading initiative known as the Strategic Sewage Disposal Scheme Project (SSDS Project) since 1995.
The reverse pump axial turbine will be installed next to the primary sedimentation tank in the plant. It will generate electricity by utilizing the potential head of wastewater from the sedimentation tank to the outfall.
Seawater is used for flushing toilets in Hong Kong, making sewage saline in the area. Primary wastewater used for power generation in this plant will therefore contain seawater too. Torishima has ensured that the water turbine is made of duplex stainless steel in order to protect the turbine from corrosion.
As for the generator, we have utilized a high efficiency and compact design permanent magnetic synchronous generator. Operators can control flow rate by adjusting speed with variable frequency drive, VFD.Previously in 2012, Torishima had delivered a reverse pump turbine (vertical, based on double-suction pump) for the Government of Hong Kong Special Administrative Region, Water Supplies Department (WSD). This turbine has exhibited stable performance for power generation to date. This reliability of the previous unit was critical for the approval of the new project.
Harnessing renewal energy has attracted increasing attention in recent years particularly among water related organizations such as WSD and DSD in Hong Kong. The demand for reverse pump turbines will be expected to grow.
Torishima is continuously contributing to improve economic and environmental conditions in Hong Kong in the years to come.
- [ 5 February 2015 ] Consolidated Financial Results for the 3rd quarter FY 2014
- [ 19 January 2015 ] Torishima wins Energy Conservation Grand Prize
